SILISIL RTV PP-Soft 00
SILISIL RTV PP-Soft 00 — Prototyping Professional-Silikon, platinvernetzend, ab Schweizer Lager.
SILISIL RTV PP-Soft 00 — Prototyping Professional.
Heat-shrink tubing, durable, anti-static option available. Shipped from our Swiss warehouse with SDS and TDS.
HS code:
3910.0000
SILISIL RTV PP-Soft 00 — Prototyping Professional
SILISIL RTV PP-Soft 00 ist ein 2K-Additionssilikon der SILISIL Prototyping-Professional-Reihe. Die Linie ist auf technische Prototypen-Fertigung und industrielle Anwendungen optimiert und deckt Shore-Härten von weich bis ultra-hart ab — inklusive einer antistatisch modifizierten Variante für elektronikaffine Umgebungen..
product benefits
- 2K addition system with a precisely calibrated mixing ratio
- Shrink-resistant and dimensionally stable even after prolonged storage
- High tear strength and tear propagation resistance
- Excellent detail reproduction, even at the microscopic level
- Long service life when installed properly
- Compatible with standard casting and impression materials
Typical applications
- Technical Prototyping: High-density castings for functional testing and design reviews
- Prototypes for series production: Small-batch and museum replicas of technical components
- ESD Environment: Antistatic Version for Electrostatic-Sensitive Areas
- Model casting: Precision impressions with a long service life
- Industrial Design: Design studies with a high level of detail
- Packaging Development: Molds for Packaging Prototypes Made of PU and Resin
Processing and Mixing
- For the exact mixing ratio, pot life, and demolding time, please refer to the technical data sheet (TDS) on this product page
- Before use, stir both components separately and then mix them thoroughly in the specified ratio
- Degassing under vacuum (30–50 mbar) removes air pockets and improves surface quality
- Apply ideally at 23 °C and 40–60% relative humidity
- Contamination from sulfur, amines, tin catalysts, or PVC must be avoided in platinum-cured systems—they prevent curing
Storage and shelf life
- Store in the unopened original container at 5–25 °C, in a dry place and protected from direct sunlight
- Shelf life from the date of manufacture as specified in the TDS — typically 12–24 months
- Close tightly after opening
Included documentation
- Technical Data Sheet (TDS) in German, English, and French
- Safety Data Sheet (SDS) under REACH
- Batch certificate upon request
SILISIL RTV PP-Soft 00 wird von SILITECH AG in der Schweiz geprüft und konfektioniert. Für Beratung zur passenden Shore-Härte, zur Wahl zwischen den verschiedenen SILISIL-Reihen oder zur Formulierungsentwicklung stehen Ihnen unsere Silikon-Spezialisten jederzeit zur Verfügung.
Technische Daten zu SILISIL RTV PP-Soft 00
| Physical properties | |
|---|---|
| Paint cured | green |
| Self-leveling | Yes |
| product information | |
|---|---|
| brand | SILISIL |
| network type | Addition (Platinum) |
| container | 1 kg + 1 kg, 5 kg + 5 kg, 10 kg + 10 kg, 25 kg + 25 kg |
| product approvals | |
|---|---|
| Certificates | RoHS, REACH |
| food contact | No |
| Suitable for medical use | No |
| Areas of application | |
|---|---|
| Main application | Formenbau, Prototyping |
| Electrical Properties | |
|---|---|
| Electrical insulation | Yes |
| General | |
|---|---|
| Density (g/cm³) | 1.03 |
| Viskosität unvernetzt (mPa·s) | 1500 |
| mixing ratio | 1:1 |
| Pot life (min) | 6 |
| Entformzeit (min) | 1 |
| Vollvernetzung (h) | 12 |
| Tensile strength (MPa) | 1.1 |
| Elongation at break (%) | 400 |
| Reißfestigkeit (N/mm) | 1.5 |
Verbindliche Werte entnehmen Sie bitte dem technischen Datenblatt (TDS) im Tab "Dokumente".
Dokumente und Datenblätter
Klicken Sie auf ein Dokument für die Vorschau oder das Download-Symbol für den direkten Download.
Häufige Fragen zu SILISIL RTV PP-Soft 00
The most important answers regarding applications, processing, and availability.
SILISIL RTV PP-Soft 00 ist ein Prototyping Professional-Silikon und wird vor allem für technisches Prototyping und Funktionsmodelle eingesetzt.
SILISIL RTV PP-Soft 00 ist ein Prototyping Professional-System, auf Basis platinvernetzender 2K-Addition, Mischungsverhältnis 1:1, Topfzeit ca. 6 Minuten bei 23 °C, Entformzeit ca. 1 Minuten, Endvernetzung nach 12 Stunden. Die exakten Werte sind als Produktattribute hinterlegt und im Shop filterbar.
SILISIL RTV PP-Soft 00 hat folgende mechanische und physikalische Kennwerte (gemäß TDS, gemessen bei 23 °C): Zugfestigkeit 1.1 N/mm², Bruchdehnung 400 %, Reißfestigkeit (Die B) 1.5 N/mm, Dichte 1.03 g/cm³, Viskosität (unvernetzt) 1500 mPa·s.
SILISIL RTV PP-Soft 00 ist ab Schweizer Lager in verschiedenen Gebindegrössen verfügbar — die genauen Abfüllungen sind als Produktvarianten auf dieser Seite aufgelistet. Für Mengen ausserhalb des Standards oder Mustermengen kontaktieren Sie unseren Vertrieb.
Ihre Frage nicht dabei?
Unser Technik-Team berät Sie persönlich bei Materialauswahl, Verarbeitungsfragen und individuellen Anforderungen — schnell und kompetent.
product specifications
| Physical properties | |
|---|---|
| Paint cured | green |
| Self-leveling | Yes |
| product information | |
|---|---|
| container | 1 kg + 1 kg or 5 kg + 5 kg or 10 kg + 10 kg or 25 kg + 25 kg |
| brand | SILISIL |
| network type | Addition (Platinum) |
| product approvals | |
|---|---|
| Certificates | RoHS or REACH |
| food contact | No |
| Suitable for medical use | No |
| Areas of application | |
|---|---|
| Main application | Mold making or Prototyping |
| Electrical Properties | |
|---|---|
| Electrical insulation | Yes |
| Uncategorized | |
|---|---|
| Density (g/cm³) | 1.03 |
| Viskosität unvernetzt (mPa·s) | 1500 |
| mixing ratio | 1:1 |
| Pot life (min) | 6 |
| Entformzeit (min) | 1 |
| Vollvernetzung (h) | 12 |
| Tensile strength (MPa) | 1.1 |
| Elongation at break (%) | 400 |
| Reißfestigkeit (N/mm) | 1.5 |
| keywords | |
|---|---|
| keywords | |
Dokumente und Datenblätter
Sicherheitsdatenblätter (SDS) und technische Datenblätter (TDS) zum Download:
