SILISIL RTV PP-Ultra 50 — Prototyping Professional-Silikon, Shore A 50, platinvernetzend, ab Schweizer Lager.
SILISIL RTV PP-Ultra 50 — Prototyping Professional Shore A 50.
Heat-shrink tubing, durable, anti-static option available. Shipped from our Swiss warehouse with SDS and TDS.
HS code:
3910.0000
SILISIL RTV PP-Ultra 50 — Prototyping Professional (Shore A 50)
SILISIL RTV PP-Ultra 50 is a two-component addition-cure silicone from the SILISIL Prototyping Professional series. The series is optimized for technical prototyping and industrial applications and covers Shore hardness ranges from soft to ultra-hard—including an antistatic-modified variant for electronics-related environments.
With a Shore A hardness of 50, the product falls into the category of medium-hard silicones (traditional mold making, prototyping).
product benefits
- 2K addition system with a precisely calibrated mixing ratio
- Shrink-resistant and dimensionally stable even after prolonged storage
- High tear strength and tear propagation resistance
- Excellent detail reproduction, even at the microscopic level
- Long service life when installed properly
- Compatible with standard casting and impression materials
Typical applications
- Technical Prototyping: High-density castings for functional testing and design reviews
- Prototypes for series production: Small-batch and museum replicas of technical components
- ESD Environment: Antistatic Version for Electrostatic-Sensitive Areas
- Model casting: Precision impressions with a long service life
- Industrial Design: Design studies with a high level of detail
- Packaging Development: Molds for Packaging Prototypes Made of PU and Resin
Processing and Mixing
- For the exact mixing ratio, pot life, and demolding time, please refer to the technical data sheet (TDS) on this product page
- Before use, stir both components separately and then mix them thoroughly in the specified ratio
- Degassing under vacuum (30–50 mbar) removes air pockets and improves surface quality
- Apply ideally at 23 °C and 40–60% relative humidity
- Contamination from sulfur, amines, tin catalysts, or PVC must be avoided in platinum-cured systems—they prevent curing
Storage and shelf life
- Store in the unopened original container at 5–25 °C, in a dry place and protected from direct sunlight
- Shelf life from the date of manufacture as specified in the TDS — typically 12–24 months
- Close tightly after opening
Included documentation
- Technical Data Sheet (TDS) in German, English, and French
- Safety Data Sheet (SDS) under REACH
- Batch certificate upon request
SILISIL RTV PP-Ultra 50 is tested and manufactured by SILITECH AG in Switzerland. Our silicone specialists are always available to assist you with advice on the appropriate Shore hardness, choosing between the various SILISIL series, or formulation development.
Technische Daten zu SILISIL RTV PP-Ultra 50
| Physical properties | |
|---|---|
| Paint cured | green |
| Self-leveling | Yes |
| product information | |
|---|---|
| brand | SILISIL |
| network type | Addition (Platinum) |
| container | 1 kg + 1 kg, 5 kg + 5 kg, 10 kg + 10 kg, 25 kg + 25 kg |
| product approvals | |
|---|---|
| Certificates | RoHS, REACH |
| food contact | No |
| Suitable for medical use | No |
| Areas of application | |
|---|---|
| Main application | Formenbau, Prototyping |
| Electrical Properties | |
|---|---|
| Electrical insulation | Yes |
| General | |
|---|---|
| Shore A hardness (cured) | A 50 |
| Viskosität unvernetzt (mPa·s) | 20'000 |
| mixing ratio | 1:1 |
| Pot life (min) | 15 |
| Entformzeit (min) | 3 |
| Tensile strength (MPa) | 4 |
| Elongation at break (%) | 320 |
| Reißfestigkeit (N/mm) | 12 |
Verbindliche Werte entnehmen Sie bitte dem technischen Datenblatt (TDS) im Tab "Dokumente".
Frequently Asked Questions About SILISIL RTV PP-Ultra 50
The most important answers regarding applications, processing, and availability.
SILISIL RTV PP-Ultra 50 ist ein Prototyping Professional-Silikon mit Shore-Härte A 50 und wird vor allem für technisches Prototyping und Funktionsmodelle eingesetzt.
SILISIL RTV PP-Ultra 50 ist ein Prototyping Professional-System, auf Basis platinvernetzender 2K-Addition, Mischungsverhältnis 1:1, Topfzeit ca. 15 Minuten bei 23 °C, Entformzeit ca. 3 Minuten. Die exakten Werte sind als Produktattribute hinterlegt und im Shop filterbar.
SILISIL RTV PP-Ultra 50 hat folgende mechanische und physikalische Kennwerte (gemäß TDS, gemessen bei 23 °C): Zugfestigkeit 4 N/mm², Bruchdehnung 320 %, Reißfestigkeit (Die B) 12 N/mm, Viskosität (unvernetzt) 20000 mPa·s.
SILISIL RTV PP-Ultra 50 ist ab Schweizer Lager in verschiedenen Gebindegrössen verfügbar — die genauen Abfüllungen sind als Produktvarianten auf dieser Seite aufgelistet. Für Mengen ausserhalb des Standards oder Mustermengen kontaktieren Sie unseren Vertrieb.
Ihre Frage nicht dabei?
Unser Technik-Team berät Sie persönlich bei Materialauswahl, Verarbeitungsfragen und individuellen Anforderungen — schnell und kompetent.
product specifications
| Physical properties | |
|---|---|
| Paint cured | green |
| Self-leveling | Yes |
| product information | |
|---|---|
| container | 1 kg + 1 kg or 5 kg + 5 kg or 10 kg + 10 kg or 25 kg + 25 kg |
| brand | SILISIL |
| network type | Addition (Platinum) |
| product approvals | |
|---|---|
| Certificates | RoHS or REACH |
| food contact | No |
| Suitable for medical use | No |
| Areas of application | |
|---|---|
| Main application | Mold making or Prototyping |
| Electrical Properties | |
|---|---|
| Electrical insulation | Yes |
| Uncategorized | |
|---|---|
| Shore A hardness (cured) | A 50 |
| Viskosität unvernetzt (mPa·s) | 20'000 |
| mixing ratio | 1:1 |
| Pot life (min) | 15 |
| Entformzeit (min) | 3 |
| Tensile strength (MPa) | 4 |
| Elongation at break (%) | 320 |
| Reißfestigkeit (N/mm) | 12 |
| keywords | |
|---|---|
| keywords | |
Dokumente und Datenblätter
Sicherheitsdatenblätter (SDS) und technische Datenblätter (TDS) zum Download:
