SILISIL RTV PC-Soft 10
SILISIL RTV PC-Soft 10 — Platin-Cast-Silikon, Shore A 10, platinvernetzend, ab Schweizer Lager.
SILISIL RTV PC-Soft 10 — Platinum-cured, Shore A 10.
Transparent, cleanroom-compatible, platinum-cured. Shipped from our Swiss warehouse with SDS and TDS.
HS code:
3910.0000
SILISIL RTV PC-Soft 10 — Platinum-Cured (Shore A 10)
SILISIL RTV PC-Soft 10 is a two-component addition-curing silicone from the SILISIL Platinum Cast series. Thanks to its platinum-based curing mechanism, the system is highly transparent, leaves no residue, and is particularly suitable for applications requiring optical clarity, close skin contact, or food-grade properties.
With a Shore A hardness of 10, the product falls into the category of very soft silicones (skin simulation, gel impressions, podiatry).
product benefits
- 2K addition system with a precisely calibrated mixing ratio
- Shrink-resistant and dimensionally stable even after prolonged storage
- High tear and tear resistance
- Excellent detail reproduction, even at the microscopic level
- Long service life when installed properly
- Compatible with standard casting and impression materials
Typical applications
- Optics / Fiber Optics: Casting of optical components, lenses, and transparent prototypes
- LED / Electronics: Encapsulation of electronic components with high dielectric strength
- Jewelry and Arts and Crafts: Clear Molds for Acrylic and Epoxy Resin Casting
- Putty / Stamping Technique: Hand-moldable impression material for the finest surfaces
- Prototyping: Dense, low-shrinkage castings with precise detail reproduction
- Product Tests: Prototypes with High Optical Transparency
Processing and Mixing
- For the exact mixing ratio, pot life, and demolding time, please refer to the technical data sheet (TDS) on this product page
- Before use, stir both components separately and then mix them thoroughly in the specified ratio
- Degassing under vacuum (30–50 mbar) removes air pockets and improves surface quality
- Apply ideally at 23 °C and 40–60% relative humidity
- Contamination from sulfur, amines, tin catalysts, or PVC must be avoided in platinum-cured systems—they prevent curing
Storage and shelf life
- Store in the unopened original container at 5–25 °C, in a dry place and protected from direct sunlight
- Shelf life from the date of manufacture as specified in the TDS — typically 12–24 months
- Close tightly after opening
Included documentation
- Technical Data Sheet (TDS) in German, English, and French
- Safety Data Sheet (SDS) under REACH
- Batch certificate upon request
SILISIL RTV PC-Soft 10 is tested and packaged by SILITECH AG in Switzerland. Our silicone specialists are always available to assist you with advice on the appropriate Shore hardness, choosing between the various SILISIL series, or formulation development.
Technische Daten zu SILISIL RTV PC-Soft 10
| product information | |
|---|---|
| container | 1 kg, 5 kg, 25 kg, 50 kg, 200 kg |
| network type | Addition (Platinum) |
| brand | SILISIL |
| Areas of application | |
|---|---|
| Main application | Elektronik-Verguss, Prototyping, LED / Optoelektronik |
| Physical properties | |
|---|---|
| Paint cured | Transparent |
| Self-leveling | Yes |
| Mechanical properties | |
|---|---|
| Shore A hardness (cured) | A 10 |
| Electrical Properties | |
|---|---|
| Electrical insulation | Yes |
| product approvals | |
|---|---|
| Certificates | RoHS, REACH |
| food contact | No |
| Suitable for medical use | No |
Verbindliche Werte entnehmen Sie bitte dem technischen Datenblatt (TDS) im Tab "Dokumente".
Keine öffentlichen Dokumente verfügbar.
Auf Wunsch senden wir Ihnen TDS und SDS gerne per E-Mail zu — Anfrage stellen.
Frequently Asked Questions About SILISIL RTV PC-Soft 10
The most important answers regarding applications, processing, and availability.
SILISIL RTV PC-Soft 10 ist ein Platin-Cast-Silikon mit Shore-Härte A 10 und wird vor allem für Elektronik-Verguss, Optoelektronik und transparente Abformungen eingesetzt.
SILISIL RTV PC-Soft 10 ist ein Platin-Cast-System, auf Basis platinvernetzender 2K-Addition. Die exakten Werte sind als Produktattribute hinterlegt und im Shop filterbar.
SILISIL RTV PC-Soft 10 ist für die oben genannten Industrieanwendungen konzipiert.
SILISIL RTV PC-Soft 10 ist ab Schweizer Lager in verschiedenen Gebindegrössen verfügbar — die genauen Abfüllungen sind als Produktvarianten auf dieser Seite aufgelistet. Für Mengen ausserhalb des Standards oder Mustermengen kontaktieren Sie unseren Vertrieb.
Ihre Frage nicht dabei?
Unser Technik-Team berät Sie persönlich bei Materialauswahl, Verarbeitungsfragen und individuellen Anforderungen — schnell und kompetent.
product specifications
| product information | |
|---|---|
| container | 1 kg or 5 kg or 25 kg or 50 kg or 200 kg |
| network type | Addition (Platinum) |
| brand | SILISIL |
| Areas of application | |
|---|---|
| Main application | Electronics encapsulation or Prototyping or LED / Optoelectronics |
| Physical properties | |
|---|---|
| Paint cured | Transparent |
| Self-leveling | Yes |
| Mechanical properties | |
|---|---|
| Shore A hardness (cured) | A 10 |
| Electrical Properties | |
|---|---|
| Electrical insulation | Yes |
| product approvals | |
|---|---|
| Certificates | RoHS or REACH |
| food contact | No |
| Suitable for medical use | No |
