Permabond ES562
Permabond® ES562 is a one-part epoxy adhesive that flows like solder when heated during curing.
HS code:
3506.9190000
Permabond® ES562 is a one-part epoxy adhesive that flows like solder when heated during curing. The adhesive exhibits excellent adhesion to metal surfaces and composites. Due to its high bond strength, this adhesive can be used in place of mechanical fasteners, soldered, or brazed joints. The adhesive has low viscosity and therefore self-levels.
product specifications
| Physical properties | |
|---|---|
| Color | white |
| Chemical group | epoxy resin |
| Viscosity (adhesives) | High viscosity >5000 mPas |
| Viscosity mPa·s | 15,000–30,000 |
| Specific gravity | 1.2 |
| product information | |
|---|---|
| container | 50 ml or 200 ml or 1 kg |
| manufacturer | Permabond Engineering Adhesives Ltd |
| brand | Permabond |
| country of origin | Italy |
| Operating temperature (°C) | -40 to +180 |
| Storage temperature (°C) | 2-7 |
| Mechanical properties | |
|---|---|
| Hardness (Shore D) | 80-85 |
| Shear strength ISO ISO4587 in N/mm² | |
|---|---|
| steel | 20-35 |
| aluminum | 14-27 |
| zinc | 14-27 |
| curing values | |
|---|---|
| Maximum gap width (mm) | 0.25 |
| Curing speed (oven) | |
|---|---|
| 130°C | 60 minutes |
| 150°C | 45 minutes |
| Performance at ultimate strength | |
|---|---|
| thermal conductivity | 0.30 W/(m·K) |
| Tensile strength (DIN53504) | 40 N/mm² |
| Elongation at break (elasticity) (DIN53504) | <3% |
| Water absorption (ISO62) 2 hours in boiling water | <0.5% |
| Uncategorized | |
|---|---|
| 160 | 20 minutes |
| modulus of elasticity | 2.1 GPa |
| Curing speed (induction) | <3 Minuten |
| TG value | 115°C |
